XPrinter XP-365B 3 Inch Label Printer with USB+LAN Interfac

Description

XPrinter XP-365B 3 Inch Thermal Label Printer with USB+LAN Interfac,127MM/S Printing Speed – Black Colour

The XPrinter XP-365B is a compact thermal printer for efficient receipt and label printing. It features a high-resolution 203 DPI and offers printing speeds up to 127 mm/s for labels and 220 mm/s for receipts. Supporting thermal roll and adhesive paper, it accommodates media widths from 20 to 82 mm and includes USB, LAN, WiFi, Bluetooth, and Serial connectivity options. With robust sensors for monitoring and a compact design (212140144mm, 0.94 kg), it’s versatile for various environments. Compatible with Windows, iOS, and Android via SDK, it operates reliably in temperatures from 5 to 45°C and humidity of 20% to 80%.

XPrinter XP-365B Product Specification:

• Model: XP-365B
• Brand Name: XPrinter
• Printing Features
  • Resolution: 203 DPI
  • Printing method: Direct Thermal
  • Max. print speed:
    • Label print mode: 127 mm/s
    • Receipt print mode: 220 mm/s
  • Max. print width: 76 mm
• Media
  • Media type: Thermal roll paper, thermal adhesive paper
  • Media width: 20~82 mm
  • Media thickness: 0.06 ~ 0.19 mm
  • Media roll diameter Max.82 mm
  • Supply method: Easy Paper Loading
• Performance Features
  • Ram: 4 M
  • FlashP 4 M
  • Interfaces
    • Label print mode: USB / USB+Lan / USB+WIFI/ USB+Bluetooth
    • Receipt print mode : USB+Lan+Serial/ USB+Serial+Lan+Bluetooth / USB+Serial+Lan+WIFI
  • Sensors
    • Label print mode: Print head temperature sensor/ Paper end/ Cover open / Gap
    • Receipt print mode: Print head temperature sensor/ Paper end/ Cover open
  • Drawer port: 1 port (Pin 2 for cash drawer)
• Fonts/Graphics/Symbologies
  • Character sizes: Commonly used in single-byte fonts; FONT 0 to FONT 8, K, TST24.BF2,TSS24.BF2
  • 1D barcode: CODE128、EAN128、ITF、CODE39、CODE39C、CODE39S、CODE93、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPCA+2、UPCA+5、UPCE、UPCE+2、UPCE+5、MSI、MSIC、PLESSEY、ITF14、EAN14
  • 2D bar code: PDF417、QRCODE、 DataMatrix
  • Emulaion:
    • Label print mode: TSPL
    • Receipt print mode: ESC/POS
• Physical Features
  • Dimension: 212*140*144mm (D*W*H)
  • Weight: 0.94 kg
• Reliability
  • Print head life: 100 km
• Software
  • Driver: Windows
  • SDK: iOS/ Android/ Windows
• Power supply
  • Input: DC 24V/2.5A
• Environmental Conditions
  • Operation environment: 5～45℃ Humidity: RH 20 ~ 80%
  • Storage environment: -40～55 ℃ Humidity:≤93% RH
